• M.2(NGFF) Connector

    • The M.2 connector, formerly known as the Next Generation Form Factor (NGFF), is a small-form-factor interface. It applies to replace mSATA. It performs high-speed, compact connectivity for SSDs, Wi-Fi, and Bluetooth modules on motherboards, utilizing PCIe, SATA, and USB protocols.

      M.2 slots are widely used in laptops and desktops for superior performance.

      Key aspects of the M.2 connector include different notches (Keys A, B, E, M) prevent incorrect installation of incompatible modules.

      • B Key: Usually for SATA or NVMe SSDs.
      • M Key: Designed for high-performance NVMe SSDs
      • B+M Key: Common on many drives to fit both B and M sockets
Total of 25 results
Please Click products below, and click Add to Inquiry List for inquiry.
  • M.2(NGFF) connector, B key, H=4.0mm, 67P, Pitch=0.5mm

    KMCX4M40B11 M.2(NGFF) connector, B key, H=4.0mm, 67P, Pitch=0.5mm

    Model: M.2 (NGFF) connector

    P/N: KMCX4M40B11

    SPEC & Feature：

    • Support B key
    • H=4.0m, 67P, Pitch=0.5mm

    Drawing

  • M.2(NGFF) connector, E key, H=4.0mm, 67P, Pitch=0.5mm

    KMCX4M40E11 M.2(NGFF) connector, E key, H=4.0mm, 67P, Pitch=0.5mm

    Model: M.2 (NGFF) connector

    P/N: KMCX4M40E11

    SPEC & Feature：

    • Support E key
    • H=4.0mm, 67P, Pitch=0.5mm

    Drawing

  • M.2(NGFF) connector, M key, H=4.0mm, 67P, Pitch=0.5mm

    KMCX4M40M11 M.2(NGFF) connector, M key, H=4.0mm, 67P, Pitch=0.5mm

    Model: M.2 (NGFF) connector

    P/N: KMCX4M40M11

    SPEC & Feature：

    • Support M key
    • M key, H=4.0mm, 67P, Pitch=0.5mm

    Drawing

  • M.2(NGFF) connector, M key, Gen4, H=4.0mm, 67P, Pitch=0.5mm

    KMCX4M40M4171 M.2(NGFF) connector, M key, Gen4, H=4.0mm, 67P, Pitch=0.5mm

    Model: M.2 (NGFF) connector

    P/N: KMCX4M40M4171

    SPEC & Feature：

    • Support M key
    • Gen4
    • H=4.0mm, 67P, Pitch=0.5mm

    Drawing

  • M.2(NGFF) connector, B/E/M key, H=6.4mm, 67P, Pitch=0.5mm

    KMCX4M64X171 M.2(NGFF) connector, B/E/M key, H=6.4mm, 67P, Pitch=0.5mm

    Model: M.2(NGFF) connector

    P/N: KMCX4M64X171

    SPEC & Feature：

    • Support B/E/M key
    • H=6.4mm, 67pins, Pitch=0.5mm

    Drawing

  • M.2(NGFF) connector, M key, Gen4, H=8.5mm, 67P, Pitch=0.5mm

    KMCX4M85M4171 M.2(NGFF) connector, M key, Gen4, H=8.5mm, 67P, Pitch=0.5mm

    Model: M.2(NGFF) connector

    P/N: KMCX4M85M4171

    SPEC & Feature：

    • Support M Key
    • Gen4
    • H=8.5mm, 67pins, Pitch=0.5mmm

    Drawing

  • M.2(NGFF) connector, B/E/M key, H=8.5mm, 67P, Pitch=0.5mm

    KMCX4M85X11 M.2(NGFF) connector, B/E/M key, H=8.5mm, 67P, Pitch=0.5mm

    Model: M.2(NGFF) connector

    P/N: KMCX4M85X11

    SPEC & Feature：

    • Support B/E/M key
    • H=8.5mm, 67P, Pitch=0.5mm

    Drawing

  • PCIe M.2 PCB Accessory of NUT and Screw

    P/N: M2HXXABEM-XXX-IMG_9306 (2) PCIe M.2 PCB Accessory of NUT and Screw

    Description: (NGFF) PCIe M.2 socket, Nut and Screw Accessory

    SPEC & Feature:

    • M.2 connector Nut and Screw
    • NUT with M3 Type, Screw with M3 Type
    • Support M.2 PCBA fixation
    • Available in various keying options for module cards
    • Support Multiple Connector Height, H=3.0mm, 4.0mm, 8.5mm
    • Metal Type

      • Application: SSD Flash Module Socket, PCB Board to Board Connector, Wi-Fi / BT / Wireless Module Socket, Networking Storage Device Cnnector

  • PCIe M.2, H=8.5mm M Key connector

    P/N: M2HXXABEM-XXX-IMG_9309 (2) PCIe M.2, H=8.5mm M Key connector

    Description: (NGFF) PCIe M.2 socket

    SPEC & Feature:

    • M.2 module connector
    • Connector Key Type: M Key
    • Position: 67pins, Pitch=0.5mm
    • Designed for both single- and double-sided modules
    • Support PCI Express 3.0, USB 3.0, and SATA 3.0 interface
    • Connector Height, H=8.5mm
    • R/A Type, Horizontal SMD Type
    • Plastic

    Application: SSD Flash Module Socket, PCB Board to Board Connector, Wi-Fi / BT / Wireless Module socket, Networking Storage Device connector

  • PCIe M.2, H=8.5mm B Key connector

    P/N: M2HXXABEM-XXX-IMG_9312 (3) PCIe M.2, H=8.5mm B Key connector

    Description: (NGFF) PCIe M.2 socket

    SPEC & Feature:

    • M.2 module connector
    • Connector Key Type: B key
    • Position: 67pins, Pitch=0.5mm
    • Designed for both single- and double-sided modules
    • Available in B key for SSD standard module cards
    • Support PCI Express 3.0, USB 3.0, and SATA 3.0 interface
    • Connector Height=8.5mm
    • R/A Type, Horizontal SMD Type
    • Plastic

    Application: SSD Flash Module Socket, PCB Board to Board Connector, Wi-Fi / BT / Wireless Module socket, Networking Storage Device connector
